BIM PLUS-T/TX SERIES
Indoor Commercial Dual-side Display
Click to play
DUAL SIDES, TWIN IMPACT
MASSIVE DISSIPATION STRUCTURE
Die-casting aluminum board with heat dissipation ribs forms massive dissipation area, enhancing display uniformity
Rear maintenance
Front maintenance
Up to 10m
FLEXIBLE INSTALLATION
Craftsmanship protection
HOB TECHNOLOGY
All-round protection
High light extraction efficiency
PRODUCT FEATURES
Versatile Sizes
Three different panel sizes (500*1000/750*250/500*250mm) enable flexible and seamless splicing
Unique Panel Design
Supports 90°rotation with highly consistentcolor performance (optional)
Stable Wireless Connection
Wireless module connectivity ensures efficientinstallation and maintenance, and secures higherstability during prolonged use
SPECIFICATION
Download parameter table
| Model | BIM Plus-T1.5(COB) | BIM Plus-T1.9 | BIM Plus-T2.6 | BIM Plus-TX1.5(COB) | BIM Plus-TX1.9 | BIM Plus-TX2.6 |
|---|---|---|---|---|---|---|
| Display Mode | Single side | Double side | ||||
| Pixel Pitch (mm) | 1.5 | 1.9 | 2.6 | 1.5 | 1.9 | 2.6 |
| Pixel Density (pixels/m²） | 409600 | 262144 | 147456 | 409600 | 262144 | 147456 |
| LED Type | COB | SMD | COB | SMD | ||
| Module Size W*H (mm) | 250*250 | |||||
| Module Resolution W*H (pixel) | 160*160 | 128*128 | 96*96 | 160*160 | 128*128 | 96*96 |
| Panel Material | Die-Casting Aluminum | |||||
| Weight (Kg/pc) | 11.5/5/3.5 | 12.5/6/4 | ||||
| Brightness (nits) | 3000 | 800-3500 | 900-3500 | 2500 | 800-2500 | 900-2500 |
| Refresh Rate (Hz) | 3840 | |||||
| Color Temperature (K) | 2000~10000 (Adjustable) | |||||
| IP Rating | IP30 | |||||
| Certifications | CB, EMC, LVD, RoHS, ETL, PSE, FCC, CCC, Tensile Test Report | |||||
* All specification values given are per panel. The specifications are for reference only, actual values may vary.
