MPA Plus-Outdoor Fixed LED Screen

MPA Plus-Outdoor Fixed LED Screen

As the first slimest fixed led panel in Esdlumen, MPA Plus is designed for outdoor fixed environment, it has suffered tough tests in hard weather with high quality, it has 3840 high refresh rate, 5000 high brighteness, -20~+60℃, all of these good features makes MPA Plus a terrific good outdoor led screens.

  • Product Origin:

    China
  • Shipping Port:

    Shenzhen
  • MOQ:

    1
  • Warranty Period:

    2 Years
  • Certificates:

    TUV-CE(EMC+LVD)/FCC
  • Stock:

    Available in Both Shenzhen & Branch Warehouse
  • Global Branch & Office:

    Netherlands/Dubai/Japan/India
  • Aftersale Service:

    Provide Global After-Sale Service
Features



1. Brilliant display effect, 5000 nits high brightness & 3840Hz high refresh rate.

2. Totally front & rear maintenance from hair to toe, all of the components from power supply, module, receiving card to cables, can do front and rear maintenance.

3. Inside concise design, no flat cable needed, good for electromagnetic shielding.

4. Fan free design, noiseless to the environment & energy saving.

5. Much lighter than traditional cabinet, weight only 30 kg/㎡, transportation cost saving.

Parameters
Model MPA Plus 3.9 MPA Plus 4.8
Pixel Pitch(mm) 3.91 4.81
Pixel Density(dot/m2) 65536 43264
LED Type SMD1921 SMD1921
Module Size(mm*mm) 250*250 250*250
Cabinet Size(mm*mm*mm) 500*500 / 500*750 / 500*1000 500*500 / 500*750 / 500*1000
Cabinet Weight(±0.25kg) 7.8 / 10.7 / 15 7.8 / 10.7 / 15
Cabinet Resolution(px*px) 128*128 / 128*192 / 128*256 104*104 / 104*156 / 104*208
Module Resolution(px*px) 64*64 52*52
Horizontal Viewing Angle(Deg) 160 160
Vertical Viewing Angle(Deg) 120 120
Brightness(cd/m2) 4500 5000
Gray Scale(bit) 16 16
Refresh Rate(Hz) 1920 1920
Max Power Consumption(W/sqm) 608 640
Average Power Consumption(W/sqm)
240 250
Input Voltage(V) AC 100-240 AC 100-240
Ingress Protection IP65 IP65
Working Environment Outdoor Outdoor
